Edimax 11AC (EW-7811UAC)

Home Wireless Network Adapter Edimax 11AC

Product Specification

General
Hardware
1 x USB 2.0 Type A
1 x Hardware WPS Button
1 x Link/Activity LED
Standards
2.4 GHz: IEEE 802.11b, 802.11g, 802.11n
5 GHz: IEEE 802.11ac (Draft), 802.11a, 802.11n
Frequency Band
2.4000 to 2.4835 GHz (subject to local regulations)
5.150 to 5.825 GHz (subject to local regulations)
Output Power
2.4 GHz
11b (11 Mb/s): 17dBm±1.5dBm
11g (54 Mb/s): 15dBm±1.5dBm
11n (20 MHz, MCS7): 14dBm±1.5dBm
11n (40 MHz, MCS7): 14dBm±1.5dBm
5 GHz
11a (54 Mb/s): 14dBm±1.5dBm
11n (20 MHz, MCS7): 13dBm±1.5dBm
11n (40 MHz, MCS7): 13dBm±1.5dBm
11ac (80 MHz, MCS9): 12dBm±1.5dBm
Installation
Multi-Language easy setup wizard
Hardware WPS button for easy wireless connections
Operating
Data Rate:
11a: 6/9/12/24/36/48/54 Mb/s
11b: 1/2/5.5/11 Mb/s
11g: 6/9/12/24/36/48/54 Mb/s
11n (20 MHz): MCS0-07 (up to 72 Mb/s)
11n (40 MHz): MCS0-07 (up to 144 Mb/s)
11ac (80 MHz): MCS0-09 (up to 433 Mb/s)
LED : Link/Activity
Security
WEP 64/128-bit, WPA, WPA2, 802.1x
Hardware & software WPS configuration
Certifications : CE/FCC
Temperature & Humidity
Maximum 95% (non-condensing)
32 to 104°F (0 to 40°C)
Dimensions (L x W x H) : 7.48 x 0.78 x 0.27" (190.00 x 20.00 x 7.00 mm)
Weight : 0.63 oz (18.00 g)
Packaging Info
Package Weight : 0.515 lb
Box Dimensions (LxWxH) : 9.55 x 5.25 x 1.85"

Edimax 11AC Dual band USB Adapter with High Gain Antenna and Free USB Extension Cradle

  (154 Total Review)
 Hot Selling

Product Features

  • High gain 4dBi/6dBi antenna
  • Dual-band 802.11N/AC Long range support
  • Includes a 1.2 m USB cradle
  • Compatible with Windows XP/Vista/7/8/8.1/10 - Mac OS 10.710.13- Linux Kernel 2.64.15 (support the distribution by Ubuntu & Fedora, others by request)
  • Max data rate 150Mbps (2.4G) + 433Mbps (5G)
$18.99

Product Specification

General
Hardware
1 x USB 2.0 Type A
1 x Hardware WPS Button
1 x Link/Activity LED
Standards
2.4 GHz: IEEE 802.11b, 802.11g, 802.11n
5 GHz: IEEE 802.11ac (Draft), 802.11a, 802.11n
Frequency Band
2.4000 to 2.4835 GHz (subject to local regulations)
5.150 to 5.825 GHz (subject to local regulations)
Output Power
2.4 GHz
11b (11 Mb/s): 17dBm±1.5dBm
11g (54 Mb/s): 15dBm±1.5dBm
11n (20 MHz, MCS7): 14dBm±1.5dBm
11n (40 MHz, MCS7): 14dBm±1.5dBm
5 GHz
11a (54 Mb/s): 14dBm±1.5dBm
11n (20 MHz, MCS7): 13dBm±1.5dBm
11n (40 MHz, MCS7): 13dBm±1.5dBm
11ac (80 MHz, MCS9): 12dBm±1.5dBm
Installation
Multi-Language easy setup wizard
Hardware WPS button for easy wireless connections
Operating
Data Rate:
11a: 6/9/12/24/36/48/54 Mb/s
11b: 1/2/5.5/11 Mb/s
11g: 6/9/12/24/36/48/54 Mb/s
11n (20 MHz): MCS0-07 (up to 72 Mb/s)
11n (40 MHz): MCS0-07 (up to 144 Mb/s)
11ac (80 MHz): MCS0-09 (up to 433 Mb/s)
LED : Link/Activity
Security
WEP 64/128-bit, WPA, WPA2, 802.1x
Hardware & software WPS configuration
Certifications : CE/FCC
Temperature & Humidity
Maximum 95% (non-condensing)
32 to 104°F (0 to 40°C)
Dimensions (L x W x H) : 7.48 x 0.78 x 0.27" (190.00 x 20.00 x 7.00 mm)
Weight : 0.63 oz (18.00 g)
Packaging Info
Package Weight : 0.515 lb
Box Dimensions (LxWxH) : 9.55 x 5.25 x 1.85"
