Product Specification
GeneralTotal Outlets6 x NEMA 5-15R
2 x NEMA 5-20R
Plug Type : NEMA L5-30P
SmartSlot Interface : 1
Communications : Serial via DE-9/DB-9
Emergency Power Off (EPO) Support : Yes
Noise Filtering : 0.3%
Topology : Double Conversion
PowerSurge Energy Rating : 480 Joules
Maximum Wattage : 2100 W
Nominal Input Voltage : 120 VAC
Input Voltage Adjustable Range : 90 to 150 VAC
Input Frequency : 50/60 Hz ± 5 Hz (Auto Sensing)
Nominal Output Voltage : 120 VAC
Output Frequency : 50/60 Hz ± 3 Hz (Configurable)
Load Capacity : 3000 VA
Thermal Dissipation : 655 BTU/Hour
Maximum Efficiency : 87.2%
Crest Factor : 3:1
Waveform : Sine Wave
BatteryCells : 1
Chemistry : Lead-Acid
Charging Time : 2.5 Hours
Replacement Battery : RBC44
EnvironmentalOperating Temperature : 32 to 104°F / 0 to 40°C
Operating Humidity : 0 to 95%
Storage Temperature : 5 to 113°F / -15 to 45°C
Storage Humidity : 0 to 95%
Operating Altitude : 10,000' / 3000 m
Storage Altitude : 50,000' / 15,000 m
Noise Level : 55 dBA
PhysicalCable Length : 8' / 2.4 m
Rackmount Size : 3 RU (with Optional Hardware)
Dimensions (W x H x D) : 5.1 x 17 x 25.9" / 13 x 43.2 x 66 cm
Weight : 120.3 lb / 54.6 kg
Packaging InfoPackage Weight : 139.6 lb
Box Dimensions (LxWxH) : 20 x 15 x 14"
