APC SMX2000 (APC-SMX2000RMLV2UNC)

Home Ups APC SMX2000

Product Specification

General
Total Outlets
3 x NEMA 5-15R
3 x NEMA 5-20R
1 x NEMA L5-20R
Plug Type : NEMA 5-20P
SmartSlot Interface : 1
Data Line Protection : RJ45
Communications
Serial via RJ45
USB via Type-B
Noise Filtering : 0.3%
Power
Surge Energy Rating : 540 Joules
Maximum Wattage : 1800 W
Nominal Input Voltage : 120 VAC
Input Voltage Adjustable Range : 75 to 154 VAC
Input Frequency : 50/60 Hz ± 3 Hz (Auto Sensing)
Nominal Output Voltage : 120 VAC
Output Frequency : 50/60 Hz ± 3 Hz
Load Capacity : 1920 VA
Thermal Dissipation : 203 BTU/Hour
Maximum Efficiency : 98%
Waveform : Sine Wave
Battery
Cells : 1
Chemistry : Lead-Acid
Charging Time : 3 Hours
Environmental
Operating Temperature : 32 to 104°F / 0 to 40°C
Operating Humidity : 0 to 95%
Storage Temperature : 5 to 113°F / -15 to 45°C
Storage Humidity : 0 to 95%
Operating Altitude : 10,000' / 3000 m
Storage Altitude : 50,000' / 15,000 m
Noise Level : 55 dBA
Certifications : REACH, RoHS, as per Manufacturer
Physical
Cable Length : 8' / 2.4 m
Rackmount Size : 2 RU (with Included Hardware)
Dimensions (W x H x D) : 17 x 3.36 x 26.26" / 432 x 85 x 667 mm
Weight : 84.6 lb / 38.5 kg
Packaging Info
Package Weight : 99.35 lb
Box Dimensions (LxWxH) : 34 x 26 x 9"

APC Network UPS, 2000VA Smart-UPS Sine Wave UPS with Extended Run Option, Network Management Card, 2U Rackmount/Tower Convertible, Line-Interactive, 120V

  (31 Total Review)
 Hot Selling

Product Features

  • 2000VA / 1800W Pure Sine Wave UPS Battery Backup
  • Smart-UPS Extended Run Option: Extended run models accept external battery packs (model SMX120RMBP2U, sold separately) for a longer runtime, to power critical servers, security, and comm systems through prolonged outages
  • Input: NEMA 5-20P Output: NEMA 5-15R (3), 5-20R (3), and L5-20R (1)
  • 2U Rackmount Rail kit included
* PC Builder™ is a participant of the Amazon Associates Program, through which we earn advertising commission on qualified sales by linking to the Amazon products.
$1,959.99
Add Product to List View on Amazon

Product Specification

General
Total Outlets
3 x NEMA 5-15R
3 x NEMA 5-20R
1 x NEMA L5-20R
Plug Type : NEMA 5-20P
SmartSlot Interface : 1
Data Line Protection : RJ45
Communications
Serial via RJ45
USB via Type-B
Noise Filtering : 0.3%
Power
Surge Energy Rating : 540 Joules
Maximum Wattage : 1800 W
Nominal Input Voltage : 120 VAC
Input Voltage Adjustable Range : 75 to 154 VAC
Input Frequency : 50/60 Hz ± 3 Hz (Auto Sensing)
Nominal Output Voltage : 120 VAC
Output Frequency : 50/60 Hz ± 3 Hz
Load Capacity : 1920 VA
Thermal Dissipation : 203 BTU/Hour
Maximum Efficiency : 98%
Waveform : Sine Wave
Battery
Cells : 1
Chemistry : Lead-Acid
Charging Time : 3 Hours
Environmental
Operating Temperature : 32 to 104°F / 0 to 40°C
Operating Humidity : 0 to 95%
Storage Temperature : 5 to 113°F / -15 to 45°C
Storage Humidity : 0 to 95%
Operating Altitude : 10,000' / 3000 m
Storage Altitude : 50,000' / 15,000 m
Noise Level : 55 dBA
Certifications : REACH, RoHS, as per Manufacturer
Physical
Cable Length : 8' / 2.4 m
Rackmount Size : 2 RU (with Included Hardware)
Dimensions (W x H x D) : 17 x 3.36 x 26.26" / 432 x 85 x 667 mm
Weight : 84.6 lb / 38.5 kg
Packaging Info
Package Weight : 99.35 lb
Box Dimensions (LxWxH) : 34 x 26 x 9"
